Product
패드인쇄용 실버 페이스트
물성표
| Items | PPP-001 |
|---|---|
| Appearance | Silver color paste |
| Binder Type | Epoxy |
| Solid Contents (wt.%) | 70.0~75.0 |
| Viscosity @ 22℃ | 10,000 ± 1,000 |
| Thixotropic Index | 5.0 ± 1.0 |
| Curing Conditions | 120 ℃, 20min |
| Sheet Resistance | 40.0 mΩ/□ |
| Adhesion | 100/100 |
| Hardness | 2H |
