Product
Adhesive for Die bonding
Technical Data Sheets
| Items | DBA-001 | UFA-001 |
|---|---|---|
| Filler | Silver | Alumina |
| Binder Type | Epoxy | Epoxy |
| Color | Grey | Ivory |
| Viscosity @ 22℃ | 25,000 ~ 30,000 | 10,000 ~ 15,000 |
| Thixotropic Index | 1.5 ~ 2.0 | 3.0 ~ 4.0 |
| Curing Conditions | 120 ℃, 20min | 120 ℃, 20min |
| Shelf Life @ -20℃, Months | 3 month | 3 month< |
| Adhesion force | 70.0 ~ 80.0 N | 80.0 ~ 90.0 N |
| Sheet Resistance | 3.00 x 1012 mΩ/□ | 1012 mΩ/□ |
